- 128CH 8MP NVR Input: 128 Channel (Via Network) • Output: HDMI(4K) x 2 dual display mode • 3U Case, 16 HDD - Hot Swap • RAID Support • Audio In/Out • Alarm In/Out • 2 x 1000Mbps Network.

VIDEO:

- Input:  2 x RJ-45 Network (1000Mbps) Support.

- Output: HDMI x 2 + VGA, Dual display mode.

- HDMI1:4K, 1920x1080 (1080P), 1280x1024.

- HDMI2 / VGA:1920x1080 (1080P), 1280x1024.

BANDWIDTH:

- Incoming: 384Mbps.

- Outgoing: 384Mbps.

DECODING SUPPORT:

- H.265, H.264.

RECORDING:

- Resolution: 8MP & lower .

- Real-Time 128CH 8MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1.

- FPS:  3200(PAL) / 3840 (NTSC).

PLAYBACK:

- 16 Channels Simultaneously (locally), 9Channels (Remotlly).

AUDIO: TWO WAY AUDIO

- Input: 1 Channel + Depends on  Camera inputs.

- Output: 1 Channel on device (RCA).

ALARM:

- Input: 8 Physical Alarm channels + IP Camera inputs.

- Output: 4 Physical Alarm channels + IP Camera outputs only.

STORAGE:

- 16 x SATA Hot swap (Up to 8TB Each).

USB PORT: TOTAL 3

- 1 x USB3.0, 2 x USB2.0.

- E-Sata x 1.

- RAID 0/1/5/6/10 Support with Hot Swap.

NETWORK: 2 X RJ-45

- 2  x 1000Mbps.
